Victron SmartSolar 150/35 MPPT Charge Regulator

Description

Victron SmartSolar 150/35 MPPT Charge Regulator

The Victron SmartSolar 150/35 MPPT Charge Controller is designed to optimise the performance of high-capacity PV systems. With a maximum charging current of 35 A and a voltage of up to 150 V , this controller offers efficiency of up to 98% thanks to ultra-fast MPPT technology. Integrated Bluetooth allows for easy remote monitoring and control via the VictronConnect app, facilitating efficient solar energy management.

Main Features

  • MPPT efficiency up to 98%
  • Maximum charging current: 35 A
  • Maximum PV input voltage: 150 V
  • Bluetooth integration for remote monitoring and control via VictronConnect
  • Compatible with 12V , 24V , 36V , and 48V batteries

Advantages or benefits

  • Optimizes solar energy capture, even in partially cloudy conditions
  • Easy configuration and remote monitoring via the VictronConnect app
  • Over temperature, short circuit and reverse polarity protection

Purpose or applications

  • Ideal for large capacity commercial or industrial solar installations
  • Perfect for projects that require efficient and remote control of solar charging

Technical specifications

  • Maximum charging current: 35 A
  • Maximum PV input voltage: 150 V
  • Absorption charging voltage range: 14.4V/28.8V/43.2V/57.6V
  • Protection: Output short circuit, over temperature
  • Operating temperature: -30°C to +60°C
  • Weight: 1.25 kg
  • Dimensions: 130 x 186 x 70 mm

In short, the Victron SmartSolar 150/35 MPPT Charge Controller is perfect for large-scale PV projects, optimising solar charging efficiency with MPPT technology and remote control via Bluetooth for more efficient energy management.

Victron SmartSolar 150/35 MPPT Charge Regulator

Product form

HeVictron SmartSolar 150/35 MPPT Charge Regulatorefficiently manages thesolar energywith a charging current of35 Aand a voltage of up to150 V, optimizing the load withBluetoothfor remote monitoring and management.

SKU: REGMPPVIC027

217,03 € 184,48 € Incl. VAT

    Specs

    Description

    Victron SmartSolar 150/35 MPPT Charge Regulator

    The Victron SmartSolar 150/35 MPPT Charge Controller is designed to optimise the performance of high-capacity PV systems. With a maximum charging current of 35 A and a voltage of up to 150 V , this controller offers efficiency of up to 98% thanks to ultra-fast MPPT technology. Integrated Bluetooth allows for easy remote monitoring and control via the VictronConnect app, facilitating efficient solar energy management.

    Main Features

    • MPPT efficiency up to 98%
    • Maximum charging current: 35 A
    • Maximum PV input voltage: 150 V
    • Bluetooth integration for remote monitoring and control via VictronConnect
    • Compatible with 12V , 24V , 36V , and 48V batteries

    Advantages or benefits

    • Optimizes solar energy capture, even in partially cloudy conditions
    • Easy configuration and remote monitoring via the VictronConnect app
    • Over temperature, short circuit and reverse polarity protection

    Purpose or applications

    • Ideal for large capacity commercial or industrial solar installations
    • Perfect for projects that require efficient and remote control of solar charging

    Technical specifications

    • Maximum charging current: 35 A
    • Maximum PV input voltage: 150 V
    • Absorption charging voltage range: 14.4V/28.8V/43.2V/57.6V
    • Protection: Output short circuit, over temperature
    • Operating temperature: -30°C to +60°C
    • Weight: 1.25 kg
    • Dimensions: 130 x 186 x 70 mm

    In short, the Victron SmartSolar 150/35 MPPT Charge Controller is perfect for large-scale PV projects, optimising solar charging efficiency with MPPT technology and remote control via Bluetooth for more efficient energy management.
