Victron BlueSolar LCD&USB 48-30 PWM Charge Regulator

Description

Victron BlueSolar LCD&USB 48-30 PWM Charge Regulator

The Victron BlueSolar LCD&USB 48-30 PWM Charge Controller is the ideal choice for **48V** solar systems with a nominal charge current of 30A . It features an LCD display for easy system monitoring and adjustment, and offers two USB outputs for charging devices. Additionally, it has advanced protections against overloads, short circuits and reverse polarity, making it safe and reliable for higher capacity applications.

Main Features

  • Rated charging current of 30A
  • Maximum solar voltage of 100V
  • Automatic load disconnection due to low voltage
  • LCD display for real-time monitoring

Advantages or benefits

  • High charging capacity for larger 48V solar applications
  • LCD display allows easy adjustment and monitoring of the system
  • Full protections against overload, short circuits and reverse polarity
  • USB outputs to charge devices while managing the solar system

Purpose or applications

  • Ideal for 48V solar projects in larger installations such as large homes, commercial installations and industrial solar systems

Technical specifications

  • Battery voltage: 48V
  • Rated load current: 30A
  • Own consumption: < 10 mA
  • Protections: Reverse polarity, short circuit, over temperature
  • Operating temperature: -35 to +60°C
  • LCD display for monitoring and configuration
  • Dimensions: 101 x 184 x 47 mm
  • Weight: 0.30 kg

The Victron BlueSolar LCD&USB 48-30 PWM Charge Controller is perfect for those who need a reliable and high-capacity controller for 48V solar applications, ensuring protection and energy efficiency.

Victron BlueSolar LCD&USB 48-30 PWM Charge Regulator

Product form

HeVictron BlueSolar LCD&USB 48-30 PWM Charge Regulatorof30AIt is perfect for solar systems of48V, with LCD screen for easy monitoring and settings.

SKU: REGPWMVIC014

71,05 € 60,39 € Incl. VAT

    Specs

    Description

    Victron BlueSolar LCD&USB 48-30 PWM Charge Regulator

    The Victron BlueSolar LCD&USB 48-30 PWM Charge Controller is the ideal choice for **48V** solar systems with a nominal charge current of 30A . It features an LCD display for easy system monitoring and adjustment, and offers two USB outputs for charging devices. Additionally, it has advanced protections against overloads, short circuits and reverse polarity, making it safe and reliable for higher capacity applications.

    Main Features

    • Rated charging current of 30A
    • Maximum solar voltage of 100V
    • Automatic load disconnection due to low voltage
    • LCD display for real-time monitoring

    Advantages or benefits

    • High charging capacity for larger 48V solar applications
    • LCD display allows easy adjustment and monitoring of the system
    • Full protections against overload, short circuits and reverse polarity
    • USB outputs to charge devices while managing the solar system

    Purpose or applications

    • Ideal for 48V solar projects in larger installations such as large homes, commercial installations and industrial solar systems

    Technical specifications

    • Battery voltage: 48V
    • Rated load current: 30A
    • Own consumption: < 10 mA
    • Protections: Reverse polarity, short circuit, over temperature
    • Operating temperature: -35 to +60°C
    • LCD display for monitoring and configuration
    • Dimensions: 101 x 184 x 47 mm
    • Weight: 0.30 kg

    The Victron BlueSolar LCD&USB 48-30 PWM Charge Controller is perfect for those who need a reliable and high-capacity controller for 48V solar applications, ensuring protection and energy efficiency.
