Victron BlueSolar LCD&USB 48-20 PWM Charge Regulator

Description

Victron BlueSolar LCD&USB 48-20 PWM Charge Regulator

The Victron BlueSolar LCD&USB 48-20 PWM Charge Controller is designed to deliver a nominal charge current of 20A on **48V** solar systems. With its LCD display, it is perfect for users who require easy monitoring and configuration. In addition, it offers two USB outputs for device charging and a range of advanced protections to keep your batteries and solar system safe.

Main Features

  • Rated charging current of 20A
  • Maximum solar voltage of 100V
  • Automatic load disconnection due to low voltage
  • LCD display for monitoring and quick setup

Advantages or benefits

  • Advanced protection against overload, short circuits and reverse polarity
  • LCD display for real-time system status monitoring
  • USB outputs to charge other devices simultaneously
  • Ideal for 48V solar systems with higher load applications

Purpose or applications

  • Perfect for 48V solar applications in large residences, commercial buildings or higher capacity solar projects

Technical specifications

  • Battery voltage: 48V
  • Rated load current: 20A
  • Own consumption: < 10 mA
  • Protections: Reverse polarity, short circuit, over temperature
  • Operating temperature: -35 to +60°C
  • LCD display for monitoring and configuration
  • Dimensions: 101 x 184 x 47 mm
  • Weight: 0.30 kg

The Victron BlueSolar LCD&USB 48-20 PWM Charge Controller is an excellent choice for users who need greater charging capacity in **48V** solar systems, guaranteeing high-level efficiency and protection.

Victron BlueSolar LCD&USB 48-20 PWM Charge Regulator

Product form

HeVictron BlueSolar LCD&USB 48-20 PWM Charge Regulatorof20AIt is ideal for solar systems of48V, with LCD screen monitoring and two USB outputs.

SKU: REGPWMVIC013

61,90 € 52,62 € Incl. VAT

    Specs

    Description

    Victron BlueSolar LCD&USB 48-20 PWM Charge Regulator

    The Victron BlueSolar LCD&USB 48-20 PWM Charge Controller is designed to deliver a nominal charge current of 20A on **48V** solar systems. With its LCD display, it is perfect for users who require easy monitoring and configuration. In addition, it offers two USB outputs for device charging and a range of advanced protections to keep your batteries and solar system safe.

    Main Features

    • Rated charging current of 20A
    • Maximum solar voltage of 100V
    • Automatic load disconnection due to low voltage
    • LCD display for monitoring and quick setup

    Advantages or benefits

    • Advanced protection against overload, short circuits and reverse polarity
    • LCD display for real-time system status monitoring
    • USB outputs to charge other devices simultaneously
    • Ideal for 48V solar systems with higher load applications

    Purpose or applications

    • Perfect for 48V solar applications in large residences, commercial buildings or higher capacity solar projects

    Technical specifications

    • Battery voltage: 48V
    • Rated load current: 20A
    • Own consumption: < 10 mA
    • Protections: Reverse polarity, short circuit, over temperature
    • Operating temperature: -35 to +60°C
    • LCD display for monitoring and configuration
    • Dimensions: 101 x 184 x 47 mm
    • Weight: 0.30 kg

    The Victron BlueSolar LCD&USB 48-20 PWM Charge Controller is an excellent choice for users who need greater charging capacity in **48V** solar systems, guaranteeing high-level efficiency and protection.
