Victron BlueSolar LCD&USB 12/24-20 PWM Charge Regulator

Description

Victron BlueSolar LCD&USB 12/24-20 PWM Charge Regulator

The Victron BlueSolar LCD&USB 12/24-20 PWM Charge Controller provides a nominal charge current of 20A for 12/24V solar systems. With its LCD display, it is easy to monitor and adjust, and features two 5V USB outputs. This controller is designed to maximise charging efficiency, protecting your batteries and solar systems with advanced safeguards.

Main Features

  • Rated charging current of 20A
  • Maximum solar voltage of 28V/55V
  • Automatic load disconnection due to low voltage
  • LCD display for easy setup and monitoring

Advantages or benefits

  • High charging capacity for larger solar systems
  • LCD display for efficient and easy control
  • USB outputs to power additional devices
  • Advanced protection against overload, short circuits and reverse polarity

Purpose or applications

  • Ideal for high capacity 12/24V solar systems such as homes, small commercial applications or RVs

Technical specifications

  • Battery voltage: 12/24V (auto detection)
  • Rated load current: 20A
  • Own consumption: < 10 mA
  • Protections: Reverse polarity, short circuit, over temperature
  • Operating temperature: -35 to +60°C
  • LCD display for monitoring and configuration
  • Dimensions: 101 x 184 x 47 mm
  • Weight: 0.30 kg

The Victron BlueSolar LCD & USB 12/24-20 PWM Charge Controller is perfect for users who need a regulator with higher capacity for larger solar systems. It maintains a high level of protection and efficiency to ensure the longevity of your batteries and solar systems.

Victron BlueSolar LCD&USB 12/24-20 PWM Charge Regulator

Product form

HeVictron BlueSolar LCD&USB 12/24-20 PWM Charge Regulatorof20AIt is designed for 12/24V solar systems, with LCD display and advanced protection.

SKU: REGPWMVIC010

37,56 € 31,92 € Incl. VAT

    Specs

    Description

    Victron BlueSolar LCD&USB 12/24-20 PWM Charge Regulator

    The Victron BlueSolar LCD&USB 12/24-20 PWM Charge Controller provides a nominal charge current of 20A for 12/24V solar systems. With its LCD display, it is easy to monitor and adjust, and features two 5V USB outputs. This controller is designed to maximise charging efficiency, protecting your batteries and solar systems with advanced safeguards.

    Main Features

    • Rated charging current of 20A
    • Maximum solar voltage of 28V/55V
    • Automatic load disconnection due to low voltage
    • LCD display for easy setup and monitoring

    Advantages or benefits

    • High charging capacity for larger solar systems
    • LCD display for efficient and easy control
    • USB outputs to power additional devices
    • Advanced protection against overload, short circuits and reverse polarity

    Purpose or applications

    • Ideal for high capacity 12/24V solar systems such as homes, small commercial applications or RVs

    Technical specifications

    • Battery voltage: 12/24V (auto detection)
    • Rated load current: 20A
    • Own consumption: < 10 mA
    • Protections: Reverse polarity, short circuit, over temperature
    • Operating temperature: -35 to +60°C
    • LCD display for monitoring and configuration
    • Dimensions: 101 x 184 x 47 mm
    • Weight: 0.30 kg

    The Victron BlueSolar LCD & USB 12/24-20 PWM Charge Controller is perfect for users who need a regulator with higher capacity for larger solar systems. It maintains a high level of protection and efficiency to ensure the longevity of your batteries and solar systems.
